ind_logoPRICE LIST

Pricelist 1
Pricelist 2

Logo PRICELIST

  • “ H-Guru” Make GL Brand Pressure Gauge, Brass Bourdon Tube, Movement and Socket, Pressed Steel M. S. Casing, Stove Enameled Black Finish, Accuracy +/-2%, Dual Scale, Temp. Limit. 90degree Celsius.

DIAL SIZE

MODEL NO.

CONNECTION

UNIT PRICE

STANDARD RANGES

50 MM 2PNNNM1 1/8" BSP (M) Rs. 275.00 VACCUM : 760mm hg to 0

Pressure : 1,2,4,7,10,14,16,21,25,28,40,70,100,140,210,
280,350,400,60kg/cm^2 & Up to 4 Ton, Compound up to 28kg/cm^2
63 MM 3PNNNM1 1/4" BSP (M) Rs. 320.00
100 MM 4PNNNM1 3/8" BSP (M) Rs. 405.00
150 MM 6PNNNM1 3/8" BSP (M) Rs. 585.00
250 MM 1PNNNM1 1/2" BSP (M) Rs. 2000.00
Note : 1. SS Casing can be offer at Extra Cost
2. Back Entry is also available at extra cost Rs.250/- for 4",6" & 10"



  • “ H-Guru” Make GL Dust and Damp Proof Non-ferrous Gauge, Accuracy +/-1%, Span Scale.

DIAL SIZE

MODEL NO.

CONNECTION

UNIT PRICE

STANDARD RANGES

100 MM 4PNNND2 3/8" BSP (M) Rs. 990.00 As above up to 70kg only -30" HG to 150 PSI, -30" HG to 300 PSI Bourdon/Movement SS 304 and Socket MS
150 MM 6PNNND2 3/8" BSP (M) Rs. 1170.00
100 MM Ammonia 1/4" NPT (M) Rs. 1220.00
Note : SS Casing can be offer at Extra Cost




  • “ H-Guru” Make Weather Proof Non-Ferrous Pressure Gauge, Accuracy +/- 1% Brass Bourdon Tube, Brass Movement, Cast Aluminium Weatherproof Case, Stove Enameled Black with screwed inner bezel of ABS plastic, Temp. Limit: 125degree Celsius, Standard Fitting Micrometer Pointer, Blow Out Disc.
  • Extra Charges for Item No. 1, 2 & 3 : Vaccum & Lower than 2kg/cm2 Rs.55/-, Compound Rs.35/- (Higher than 70 to 700 kg/cm2 Rs.275/-)

DIAL SIZE

MODEL NO.

CONNECTION

UNIT PRICE

STANDARD RANGES

100 MM 4PNNNW2 3/8" BSP (M) Rs. 1545.00 As Above up to 70kg only
150 MM 6PNNNW2 3/8" BSP (M) Rs. 1870.00
250 MM 1PNNNW2 1/2" BSP (M) Rs. 2930.00
Note : 1. SS Casing can be offer at Extra Cost
2. Back Entry is also available at extra cost Rs. 250.00





  • “ H-Guru” Make Stainless Steel Pressure Gauge, Accuracy +/- 1%, SS316 Bourdon Tube, SS304 Movement, Cast Aluminium WeatherProof Case, Stove Enameled Black with screwed Inner Bezel of ABS plastic, Temp. Limit: 270degree Celsius, Standard Fitting: Micrometer Pointer, Blow Out Disc
  • Extra Charges :- Vaccum & Lower than 2kg/cm^2 Rs.750/-, Compound Rs.225/- (Higher than 70 to 600 kg/cm^2 Rs. 225/- & 700 kg/cm^2 Rs.1000 kg/cm^2 Rs.770/- For 1600 to 2000 kg/cm^2 Rs. 2750/- Glycerine Filled for Rs.350/- 4" & 6", Dial Rs.550/-.

DIAL SIZE

MODEL NO.

CONNECTION

ALU CASING UNIT PRICE

SS CASING UNIT PRICE

STANDARD RANGES

50 MM 2PSSSW2  1/8" BSP (M)

Rs. 1050.00

1,2,4,7,10,11,14,16,21,25,28,35,40,70,100-700 kg/cm^2 Vac : 760 MMHG to 0 Comp -1+1, -1+2, -1+4, -1+10,-1+14,-1+21kg/cm^2
63 MM 3PSSSW2 1/4" BSP (M)

Rs. 1150.00

100 MM 4PSSSW2 1/2" NPT (M) Rs. 1610.00

Rs. 1790.00

150 MM 6PSSSW2 1/2" NPT (M) Rs. 1810.00

Rs. 2035.00

250 MM 1PSSSW2 1/2" BSP (M) Rs. 3525.00

Rs. 4500.00

Note : Back Entry is also available at extra cost Rs. 250/-




  • “ H-Guru” Make Schaffer's Diaphragm Pressure Gauge, Accuracy +/- 1.5% Brass Movement , Spring steel diaphragm with Teflon foil protection, Cast Aluminium Weatherproof Case, Stove Enameled Black with screwed bezel, Bottom Chamber & connection SS304
  • Extra Charges : Vaccum and Compound Rs. 200/-

DIAL SIZE

MODEL NO.

CONNECTION

UNIT PRICE

STANDARD RANGES

100 MM 4PDASW2

1/2" BSP (M)

Rs. 1960.00 0-1,2,4,7,10,14,21,28 kg/cm^2
Vac : 760 MMHG to 0 Comp -1+1, -1+2, -1+4, -1+10, -1+14, kg/cm^2
150 MM 6PDASW2

1/2" BSP (M)

Rs. 2100.00




  • “ H-Guru” Make Sealed Diaphragm Gauge, Accuracy +/- 1% Non-Ferrous/ SS Bourdon Block Movement, Instrument connection 1/4" NPT, Process connection 1/2" BSP (M) (Flange connection available in different specification) sensing element SS Diaghragm, Sealing Fluid, Silicon (upto 170degree Celcius) Die Cast Aluminium Weatherproof Case, top & Bottom Chamber SS304
  • Extra Charges :- For 1 Mtr SS Capillary Rs. 700/- Ask for different applications/mountings/connections , high temperature.

DIAL SIZE

MODEL NO.

UNIT PRICE

MODEL NO.

UNIT PRICE

STANDARD RANGES

100 mm 4PDNSSW2 Rs. 3490.00

4PDSSSW2

Rs.3815.00

NOTE : Please refer Table of SSPG for extra charges & ranges
150 mm 6PDNSSW2 Rs. 3605.00

6PDSSSW2

Rs.3915.00

Note : 1. SS Casing can be offer at Extra Cost.
2. Back Entry is also available at extra cost Rs.250/-




  • “ H-Guru” Make Differential Pressure Guage :

MODEL NO.

MAX. STATIC PRESSURE

DIFFERENTIAL RANGE

UNIT PRICE



6DPSSW2  100kg/cm^2

0-1kg/cm^2 to 0-25kg/cm^2

Rs.15020.00

6DPSSW2  40kg/cm^2 0-600mmwc to 6000mmwc

Rs.23075.00

6DPSSW2  40kg/cm^2 0-200mmwc to 400mmwc

Rs.27800.00





  • “ H-Guru” Make Capsule Type , (Low Range) Pressure Gauge, Accuracy +/- 1.5%, Connection 1/2" BSP (M) Non-Ferrous Movement, sensing element : SS316 diaphragm, bottom chamber : SS316, Die Cast Aluminium case Stove enameled black finish with screwed bexel, mounting : bottom direct (kindly ask for ACC +/- 1% FSD)
  • Extra Charge for Compund Range Rs.250/-

DIAL SIZE

MODEL NO.

CONNECTION

UNIT PRICE

STANDARD RANGES

100 MM 4PCSAW2 1/2" BSP (M)

Rs. 2875.00

0-160,250,400,600,1000,1200,1500,1600,
2000,2500,3000,4000,5000,6000,10000mmwc
150 MM 6PCSAW2 1/2" BSP (M)

Rs. 3000.00

Note : Compact Type Capsule pressure Gauge is also available at extra cost.




  • “ H-Guru” Make Receiver Pressure Gauge, Accuracy +/- 1% Non-Ferrous/ SS Bourdon & Movement connection 1/4" NPT (M), die cast aluminium weatherproof case , Range 3 to 15PSI, 0.2 to 1kg/cm^2 with 100% linear of 10sq. root scale
  • Mounting : M1/W1 : Bottom connection projection / surface, D2/M2/W2 : Bottom Connection Direct, M3/W3 : Connection Direct, M5/W5 : Back Connection Panel Mounting.

DIAL SIZE

MODEL NO. N.F.

UNIT PRICE

MODEL NO. S.S

UNIT PRICE

100 MM 4RNNNW2 Rs. 2530.00 4RSSSW2 Rs. 3530.00
150 MM 6RNNNW2 Rs. 2710.00

6RSSSW2

Rs. 3950.00




  • “ H-Guru” Make Draught Gauge, Accuracy +/-1%, connection 1/4"BSP(M) Brass Movement, Sensing Element : NF/SS Capsule, Flush Panel with Back Entry, Fabricated Steel, Painted Stove enameled

DIAL SIZE

MODEL NO. (NF)

UNIT PRICE

MODEL NO. (SS)

UNIT PRICE

STANDARD RANGES

150X78mm 6FPNNMS Rs. 7845.00

6FPSSM5

Rs.9505.00

0-50,60,100,160,200,250,400,1600
,1000,1000,1200,1600,2000,2500,4000,600mmwc,
Compound ranges are also available at extra cost
200x78mm 8FPNNMS Rs. 9500.00

8FPSSM5

Rs.9940.00






Dial Thermometer

  • “ H-Guru” Make Mercury in Steel Thermometer :- 3/4" BSP (M), Accuracy +/- 1% bulb and connection material mild steel, adjustable type gland, cast aluminium weatherproof case, stove enameled black with screwed inner bezel of ABS plastic, bulb dia: 16/12 mm, Stem Dia : 9 mm, Immersion Length : 250 mm adjustable between 100 to 250 mm

RIGID M.S STEM TYPE

UNIT PRICE

3 MTR COPPER CAPILLARY

UNIT PRICE

STANDARD RANGES

4HRMW3(4") Rs. 3070.00 4HDMCW1(4") Rs. 3785.00 -38+50, -10+100, 0-50, 0-65,0-100, 120,150,200,250,300,400,500,600degree Celcius
6HRMW3(6") Rs. 3270.00 6HDMCW1(6") Rs. 4120.00
1HRMW310") Rs. 4325.00 1HDMCW1(10") Rs. 5340.00
Note. 1. SS Casing can be offer at Extra Cost.
2. Back Entry is also available at extra cost Rs. 250/-




  • “ H-Guru” Make Mercury in Steel Thermometer :- SS Working parts other specifications as per item No. (1)
  • Extra charges : For Ranges : -38 + 50 , 0 - 50 & 0 - 65 degree Celcius : Rs.1020/- For Item 1 & 2

RIGID S.S STEM

UNIT PRICE

3 MTR S.S CAPILLARY

UNIT PRICE

STANDARD RANGES

4HRSW3(4") Rs. 3570.00 4HDSSW1(4") Rs. 4690.00 As above
6HRSW3(6") Rs. 3850.00 6HDSSW1(6") Rs. 4865.00
1HRSW3(10") Rs. 6405.00 1HDSSW1(10") Rs. 8505.00
Note . 1. SS Casing canbe offer at Extra Cost.
2. Back Entry is also available at extra cost Rs. 250/-




  • “ H-Guru” Make Liquid Filled Temperature Gauge : 3/4" (M),Accuracy +/-1.5%, Bulb & Connection material Mild Steel, Adjustable Type Gland, Cast Aluminium weatherproof case, Stove enameled Black with screwed inner Bezel of ABS Plastic, Bulb Dia : 16/12mm, Stem Dia:9mm, Immersion Length : 250mm, Adjustable between 100 to 250mm.

RIGID M.S STEM TYPE

UNIT PRICE

3 MTR COPPER CAPILLARY (DISTANCE TYPE)

UNIT PRICE

STANDARD RANGES

4LRMW3(4") Rs. 2160.00 4LDMCW1(4") Rs. 2745.00 -38+50, -10+100, 0-50, 0-65, 0-100, 120, 150,200 degree Celcius
Max.Capilary Length : 5Mtrs only
6TRNW3(6") Rs. 2360.00  6LRMW3(6") Rs. 3180.00
6TRNW3(6") Rs. 3535.00 1LRMW3 (10") Rs. 4400.00




  • “ H-Guru” Make Liquid Filled Temperature G : S.S. Working Parts rest specification as per Item No. 1

RIGID (S.S.STEM TYPE)

UNIT PRICE

3 MTR BRASS CAPILLARY (DISTANCE TYPE)

UNIT PRICE

STANDARD RANGES

4LRSW3(4") Rs. 2750.00 4LDSSW1(4") Rs. 3725.00

As Above

6LRSW3(6") Rs. 2985.00 6LDSSW1(6") Rs. 3990.00
1LRSW3(10") Rs. 4185.00 1LDSSW1(10") Rs. 6590.00




  • “ H-Guru” Make Bimettalic Thermometer : 1/2" BSP (M), Accuracy +/-1.5%, Bulb & Connection material SS, Aluminium weatherproof case, Stove enameled Black with screwed inner Bezel of ABS Plastic, Stem Dia : 8mm, Immersion Length : 150mm (Standard)

MODEL/SIZE VERTICAL TYPE

UNIT PRICE

HORIZONTAL BACK ENTRY

UNIT PRICE

STANDARD RANGES

4BSW3(4") Rs. 1390.00 4BSW7(4") Rs. 995.00
6BSW3(6") Rs. 1590.00 6BSW7(6") Rs. 1140.00
Note : Quality Type with Accuracy +/-1% and All Angle can be offer at extra cost.




  • “ H-Guru” Make Vapour Pressure Therometer : Connection 3/4" BSP(M), Accuracy +/-1%, Bulb & Connection material non ferrous, Cast aluminium weatherproof case, Stove enameled black with screwed inner bezel of ABS plastic, Bulb dia : 14mm, stem dia : 8mm, Immersion Length : adjutable between 100 to 250mm

RIGID STEM TYPE

UNIT PRICE

3 MTR COPPER CAPILLARY COVERED WITH PVC TUBE

UNIT PRICE

STANDARD RANGES

4TRNW34") Rs. 1345.00 4TDNRW1(4") Rs. 1850.00 -10+65, 0-100, 120, 150, 200, 260, 340degree celcius
6TRNW3(6") Rs. 1670.00 6TDNRW1(6") Rs. 1960.00
W1. Projection Mounting with bottom entry, W3 vertical with Bottom Entry, W5 : Flush Panel with back Entry, W7 : Horizontal with back entry. Extra charges for Back entry Rs.250/-




ALL ACCESSORIES FOR PRESSURE GAUGE AND TEMPERATURE GAUGE ARE ALSO AVAILABLE AT EXTRA COST.

OTHER PRODUCTS & ACCESSORIES : ELECTRICAL CONTACTS, HOMOGINIZER GAUGES, MERCURY IN STEEL, BI METALLIC & VAPOUR PRESSURE TYPE DIAL THERMOMETER, PRESSURE AND TEMPERATURE RECORDER, DEAD-WEIGHT.

TERMS AND CONDITONS

  • Taxes : as applicable.
  • Packing and Forwarding : Extra
  • Kindly ASK FOR DISCOUNT
  • Price List : Subject to change without notice
  • Stock : Subject to availability.
  • This cancels all our previous Price List
